The Imaging Source ViC 47GX568-I67 5 MP GigE Kamera

Name: The Imaging Source ViC 47GX568-I67 5 MP GigE Kamera
Brand: GigE

Fiyat için teklif alın

B2B ürünlerimizde güncel fiyat ve stok bilgisi için teklif talep edin — aynı gün dönüş yapıyoruz.

1/1.8" IMX568 sensör, 2448×2048 (5 MP), 23 fps, Global shutter, GigE arabirim, The Imaging Source üretimi

Tüm teknik özellikleri gör

Hemen Arayın

Kategori: Area Scan, Endüstriyel Kameralar Etiketler: GigE, Global Shutter, Renkli, The Imaging Source Destek: Kurulum, entegrasyon ve yazılım desteği Gökser Vision güvencesiyle.

Detaylar

Teknik Özellikler

GENERAL BEHAVIOR
Dynamic Range	12 bit
Resolution	2,448 × 2,048 ( 5 MP )
Frame Rate	23 fps
Video Output Format	8-Bit Bayer (GB), 12-Bit Bayer Packed (GB), 16-Bit Bayer (GB), YUV 4:2:2, YUV 4:1:1, YUV 4:1:1, RGB24, 8-Bit Monochrome, 12-Bit Packed Monochrome, 16-Bit Monochrome
INGRESS PROTECTION
Protection Rating	IP6K6 and IP6K7
ISO Standard	ISO 20653
Solid Particle Protection	6K (maximum protection)
Liquid Ingress Protection	6 (powerful water jets)
Additional Liquid Ingress Protection	7 (immersion up to 1 m)
INTERFACE (OPTICAL)
Sensor Type	Pregius S
Sensor Specification	Sony IMX568
Shutter	Global
Format	1 / 1.8 inch
Pixel Size	H: 2.74 µm, V: 2.74 µm
Sensor Size	H: 6,7 mm, V: 5,6 mm
Sensor Diagonal	8,7 mm
Lens Mount	M12x0.5
Lens Tube	IP67 Tube must be ordered separately
M12 Lens	S-Ultra M12 lens must be ordered separately
INTERFACE (ELECTRICAL)
Interface	GigE
Supply Voltage	4.75 VDC to 14 VDC or POE: 48 VDC to 56 VDC
Power Consumption:	2.7 W PoE
Current Consumption	Approx. 170 mA @ 12 VDC
Auto-Iris Control
Trigger
I/O
INTERFACE (MECHANICAL)
Dimensions	H: 43 mm, W: 43 mm, L: 34.5 mm
Mass	110 g
ADJUSTMENTS
Shutter	18 µs to 4 s
Gain	0 dB to 48 dB
ENVIRONMENTAL
Housing Temperature (Operating)	0 °C to 50 °C
Temperature (Storage)	-20 °C to 80 °C
Humidity (Operating)	20 % to 80 % (non-condensing)
Humidity (Storage)	20 % to 95 % (non-condensing)
