Description

SP-12000C-CXP4

The SP-12000C-CXP4 provides 12-megapixel color resolution at a blazing fast 189 frames per second – the fastest 12-megapixel camera in the industry. Built around the CMOSIS CMV12000 CMOS imager, it is capable of handling the most demanding of high performance machine vision applications.

Specifications

Product Line: Spark Series

Model: SP-12000C-CXP4

Type: Area Scan

Color / Mono: Color

Light Spectrum: Visible

Resolution: 12.0 MP

Resolution WxH: 4096 x 3072 px

Frame rate / Line rate: 189 fps

ROI: Yes

Interface: CoaXPress 4-Cable CXP-6 (PoCXP)

Sensor: 1XCMOS

Sensor Name: CMV12000

Optical Format: APS-C

Cell Size WxH: 5.5 x 5.5 µm

Shutter type: Global shutter

Sensor Diagonal: 28.2 mm

Active Sensor Dimensions WxH: 22.5 x 16.9 mm

Camera Dimensions HxWxL: 62 x 62 x 127.5 mm

Weight: 510 g

Video Output: 8/10/12-bit *

Lens Mount: F-mount or M-42×1 mount

Power Consumption: 11.40 Watt

Operating Temperature (ambient): -5°C to +30°C

* Some video processing functions not available with 12-bit output
