Product Line: Go Series
Model: GO-5000C-USB
Type: Area Scan
Color / Mono: Mono
Light Spectrum: Visible
Resolution: 5.0 MP
Resolution WxH: 2560 x 2048 px
Frame rate / Line rate: 62 fps
Beğenilerine Ekle
Beğenilerine Ekle
Description
GO-5000M-USB
The GO-5000M-USB is a compact industrial area scan camera delivering an excellent blend of size, versatility, and performance, all at an entry-level price. It delivers 5-megapixel raw Bayer color output at up to 62 fps, with flexible ROI capabilities that enable the camera to be tailored to a wide range of machine vision applications.
Specifications
Product Line: Go Series
Model: GO-5000M-USB
Type: Area Scan
Color / Mono: Mono
Light Spectrum: Visible
Resolution: 5.0 MP
Resolution WxH: 2560 x 2048 px
Frame rate / Line rate: 62 fps
ROI: Yes
Interface: USB3 Vision (PoUSB)
Sensors: 1XCMOS
Sensor Name: Lince5M
Optical Format: 1 inch
Cell Size WxH: 5.0 x 5.0 µm
Shutter type: Global shutter
Sensor Diagonal: 16.4 mm
Active Sensor Dimensions WxH: 12.8 x 10.2 mm
Camera Dimensions HxWxL: 29 x 29 x 41.5 mm
Weight: 46 g
Video Output: 8/10/12-bit
Lens Mount: C-mount
Power Consumption: 3.60 Watt
Operating Temperature (ambient): -5°C to +45°C
