Description

GO-5100M-PGE

The GO-5100M-PGE is a compact industrial area scan camera delivering an excellent blend of size, versatility, and performance, all at an entry-level price. It delivers 5-megapixel raw Bayer color output at up to 22.7 fps while offering exceptionally low-noise image quality for a wide range of machine vision applications.

Specifications

Product Line: Go Series

Model: GO-5100M-PGE

Type: Area Scan

Color / Mono: Mono

Light Spectrum: Visible

Resolution: 5.1 MP

Resolution WxH: 2464 x 2056 px

Frame rate / Line rate: 22 fps

ROI: Yes

Interface: GigE Vision 1-Cable (PoE)

Sensors: 1XCMOS

Sensor Name: IMX250

Optical Format: 2/3 inch

Cell Size WxH: 3.45 x 3.45 µm

Shutter type: Global shutter

Sensor Diagonal: 11.1 mm

Active Sensor Dimensions WxH: 8.5 x 7.1 mm

Camera Dimensions HxWxL: 29 x 29 x 41.5 mm

Weight: 46 g

Video Output: 8/10/12-bit *

Lens Mount: C-mount

Power Consumption: 3.99 Watt

Operating Temperature (ambient): -5°C to +45°C

* Some video processing functions not available with 12-bit output
