Description

SP-20000M-PMCL

The SP-20000M-PMCL provides 20-megapixel color resolution at a market-leading 30 frames per second. Built around the CMOSIS CMV20000 CMOS imager, it offers a rare combination of high resolution, high frame rate, and high image quality, well suited to a wide range of high performance applications.

Specifications

Product Line: Spark Series

Model: SP-20000M-PMCL

Type: Area Scan

Color / Mono: Mono

Light Spectrum: Visible

Resolution: 20.0 MP

Resolution WxH: 5120 x 3840 px

Frame rate / Line rate: 30 fps

ROI: Yes

Interface: Mini Camera Link (PoCL)

Sensors: 1XCMOS

Sensor Name: CMV20000

Optical Format: 41.0 mm

Cell Size WxH: 6.4 x 6.4 µm

Shutter type: Global shutter

Sensor Diagonal: 41.0 mm

Active Sensor Dimensions WxH: 32.8 x 24.6 mm

Camera Dimensions HxWxL: 62 x 62 x 84.5 mm

Weight: 320 g

Video Output: 8/10/12-bit *

Lens Mount: F-mount or M-42×1 mount

Power Consumption: 5.40 Watt

Operating Temperature (ambient): -45°C to +70°C

* Some video processing functions not available with 12-bit output
