Description

SW-8000M-PMCL

The SW-8000M-PMCL is a high speed monochrome line scan camera featuring a custom-designed 8K monochrome line sensor capable of running at up to 100,000 lines per second. The CMOS imager features 3.75-micron by 5.78-micron rectangular pixels offering excellent sensitivity for high-speed applications.

Specifications

Product Line: Sweep Series

Model: SW-8000M-PMCL

Type: Line Scan

Color / Mono: Mono

Light Spectrum: Visible

Resolution: N/A

Resolution WxH: 8192 x 1 px

Frame rate / Line rate: 100 kHz

ROI: N/A

Interface: Mini Camera Link (PoCL)

Sensors: 1XCMOS

Sensor Name: Custom

Optical Format: 30.72 mm

Cell Size WxH: 3.75 x 5.78 µm

Shutter type: Global shutter

Sensor Diagonal: 30.8 mm

Active Sensor Dimensions WxH: 30.8 mm

Camera Dimensions HxWxL: 62 x 62 x 84 mm

Weight: 320 g

Video Output: 8/10-bit

Lens Mount: F-mount or M-42×1 mount

Power Consumption: 5.22 Watt

Operating Temperature (ambient): -5°C to +45°C
