Description

SW-4000M-PMCL

The SW-4000M-PMCL is a high speed monochrome line scan camera featuring a custom-designed 4K monochrome line sensor capable of running at up to 200,000 lines per second. An innovative built-in function allows users to switch between large and small pixel well sizes to tailor the responsivity and dynamic range of the camera to fit the speed and illumination requirements of their application.

Product Line: Sweep Series

Model: SW-4000M-PMCL

Type: Line Scan

Color / Mono: Mono

Light Spectrum: Visible

Resolution: N/A

Resolution WxH: 4096 x 1 px

Frame rate / Line rate: 200 kHz

ROI: N/A

Interface: Mini Camera Link (PoCL)

Sensors: 1XCMOS

Sensor Name: Custom

Optical Format: 30.72 mm

Cell Size WxH: 7.5 x 7.5 µm

Shutter type: Global shutter

Sensor Diagonal: 30.8 mm

Active Sensor Dimensions WxH: 30.8 mm

Camera Dimensions HxWxL: 62 x 62 x 84 mm

Weight: 320 g

Video Output: 8/10-bit

Lens Mount: F-mount or M-42×1 mount

Power Consumption: 5.22 Watt

Operating Temperature (ambient): -5°C to +45°C
